T51XW-EU

Model: T51XW
Construction / Protection: 304 stainless steel NEMA 4X / IP66 enclosure, 304 stainless steel wall mount bracket with adjustment knobs
Full Scale Capacity Range: 1 to 999,950 kg/lb
Max Displayed Resolution: 1:30,000d
Maximum Approved Resolution: 1:10,000e / Dual range 1:3000e
Maximum Counting Resolution: 1:300,000d
Min Average Piece Weight (APW): 0.1d
Weighing Units: kg, lb, g, oz, lb:oz, tonnes, custom
Weight Display: 6-digit, 7-segment LCD, 25mm High digits, with high-contrast white LED backlight
Checkweigh Indication: 3-colour LED with configurable beeper signal
Keyboard: 4 function membrane switches, with positive feedback
Extra Functions/Modes: Display Hold, Dynamic Weighing, Counting, Checkweighing, Percent Weighing
Other Software Features: Zero calibration, Calibration test, Geographical gravity adjustment, Auto-tare, Auto-tare on-accept, GMP Time-Date, Key function lock, temporary display of higher resolution
Load Cell Excitation Voltage: 5V DC
Load Cell Input Sensitivity: up to 3 mV/V
Load Cell Drive: up to 8 x 350 Ω load cells
Stabilization Time: within 2 seconds
Zeroing Range: 2% or 100% of capacity
Span Calibration: 1 kg/lb to 100% of capacity
Interface: Built-in RS232 and external input / Optional RS422/485 / optional AC Relay / optional DC relay / optional 2^nd RS232
Operating Temperature Range: -10°C to 40°C
Relative Humidity Range: Maximum 80% up to 31°C, decreasing linearly to 50% at 40°C
Power: 100-240 VAC / 50-60 Hz, internal universal power supply, hard-wire cord, optional internal rechargeable NiMH battery (30-hr. typical operation)
Enclosure Dimensions: 262W x 76D x 149H mm
Overall Dimensions (inc. bracket): 315W x 76D x 212H mm
Net / Shipping Weight: 3.5 kg / 4.3 kg
Shipping Dimensions: 330W x 240D x 180H mm

IQ/OQ/PQ service: Yes, possible

Prikaži više

Raspoloživost: Na lageru

Ukoliko zelite da narucite proizvod, saznate vise o proizvodu ili potrazite strucni savet molimo vas kliknite na dugme Kontakt i popunite formu.

Detalji

Smart Functionality, Durability, OHAUS Quality & Value

The OHAUS Defender™ 5000 Series is a feature-rich line of indicators, bases and bench scales that is ideal for washdown environments in shipping and receiving, production, packing and general commercial and industrial weighing applications. The Defender 5000 for washdown applications features durable all-stainless steel bases and columns. Its IP66 stainless steel indicator is a powerful weighing machine; by enabling its various modes, you have the flexibility to customize the scale for a wider variety of specific applications at no additional cost or complexity. With rugged construction, comprehensive yet intuitive software operations, multiple connectivity options, optional NiMH battery operation and flexible mounting capabilities, the Defender 5000 is your dependable one-product solution for an expandable range of weighing operations.

Standard Features Include:

- Five popular capacities: 15kg, 30kg, 60kg, 150kg and 300kg, three platform sizes: 30. 5 x 30. 5cm, 45. 7 x 45. 7cm and 61 x 61cm
- All stainless steel bases and scales with OIML R60 approved IP67 stainless steel load cell
- Scale displayed resolutions 1:12,000-15,000 (with temporary high resolution display), approvable to 1:3000e
- Stainless steel IP66 indicator with displayed resolutions up to 1:30000, and drives up to 8 x 350 Ωs load cells
- High contrast single-line backlit LCD display with 25mm tall digits, 3-colour checkweigh LED and setpoint beeper
- Four function keys, raised, tactile membrane switches with menu navigation text and key-press beeper
- Multiple weighing units: kg, g, lb, oz, lb:oz, t and custom unit
- Multiple user-activated modes: counting (with auto-optimization), checkweighing, percent weighing, dynamic-animal weighing and display hold
- Universal switching power supply with optional rechargeable NiMH battery
- Built-in RS232 and external input, with optional 2^nd RS232, RS422/485, AC and DC relay kits
