Model: D30HR
Capacity (Max): 30kg
Construction: 304 stainless steel pan, painted carbon steel frame, non-slip rubber leveling feet
Leveling Components: Externally visible level bubble and adjustable leveling feet
Operating Temperature : -10°C to 40°C
Safe Overload Capacity: 150% of rated capacity
Load Cell Type: IP67, aluminum, single point / C3
Load Cell Cable: 2m L x 6-wire
Load Cell Rated Output: 2 mV/V ± 10%
Load Cell Excitation Voltage: Maximum 20V (AC/DC) / Recommended 5to15V (AC/DC)
Load Cell Input / Output Resistance: 410 ± 10 Ωs / 350 ± 4 Ωs
Base Dimension (AxBxCxDxE) (mm): 355 x 305 x 95 x 50 x 380
Shipping Dimensions (mm): 490L x 410W x 440H
Net / Shipping Weight: 9 kg / 11 kg

IQ/OQ/PQ service: Yes, possible

Model: D60HR
Capacity (Max): 60kg
Construction: 304 stainless steel pan, painted carbon steel frame, non-slip rubber leveling feet
Leveling Components: Externally visible level bubble and adjustable leveling feet
Operating Temperature : -10°C to 40°C
Safe Overload Capacity: 150% of rated capacity
Load Cell Type: IP67, aluminum, single point / C3
Load Cell Cable: 2m L x 6-wire
Load Cell Rated Output: 2 mV/V ± 10%
Load Cell Excitation Voltage: Maximum 20V (AC/DC) / Recommended 5to15V (AC/DC)
Load Cell Input / Output Resistance: 410 ± 10 Ωs / 350 ± 4 Ωs
Base Dimension (AxBxCxDxE) (mm): 355 x 305 x 95 x 50 x 380
Shipping Dimensions (mm): 490L x 410W x 440H
Net / Shipping Weight: 9 kg / 11 kg

IQ/OQ/PQ service: Yes, possible

Model: D60HL
Capacity (Max): 60kg
Construction: 304 stainless steel pan, painted carbon steel frame, non-slip rubber leveling feet
Leveling Components: Externally visible level bubble and adjustable leveling feet
Operating Temperature : -10°C to 40°C
Safe Overload Capacity: 150% of rated capacity
Load Cell Type: IP67, aluminum, single point / C3
Load Cell Cable: 2m L x 6-wire
Load Cell Rated Output: 2 mV/V ± 10%
Load Cell Excitation Voltage: Maximum 20V (AC/DC) / Recommended 5to15V (AC/DC)
Load Cell Input / Output Resistance: 410 ± 10 Ωs / 350 ± 4 Ωs
Base Dimension (AxBxCxDxE) (mm): 500 x 400 x 105 x 60 x 530
Shipping Dimensions (mm): 740L x 690W x 230H
Net / Shipping Weight: 19 kg / 22 kg

IQ/OQ/PQ service: Yes, possible

Model: D150HX
Capacity (Max): 150kg
Construction: 304 stainless steel pan, painted carbon steel frame, non-slip rubber leveling feet
Leveling Components: Externally visible level bubble and adjustable leveling feet
Operating Temperature : -10°C to 40°C
Safe Overload Capacity: 150% of rated capacity
Load Cell Type: IP67, aluminum, single point / C3
Load Cell Cable: 2m L x 6-wire
Load Cell Rated Output: 2 mV/V ± 10%
Load Cell Excitation Voltage: Maximum 20V (AC/DC) / Recommended 5to15V (AC/DC)
Load Cell Input / Output Resistance: 410 ± 10 Ωs / 350 ± 4 Ωs
Base Dimension (AxBxCxDxE) (mm): 550 x 420 x 125 x 70 x 580
Shipping Dimensions (mm): 750L x 710W x 230H
Net / Shipping Weight: 24.5 kg / 27 kg

IQ/OQ/PQ service: Yes, possible

Model: D300HX
Capacity (Max): 300kg
Construction: 304 stainless steel pan, painted carbon steel frame, non-slip rubber leveling feet
Leveling Components: Externally visible level bubble and adjustable leveling feet
Operating Temperature : -10°C to 40°C
Safe Overload Capacity: 150% of rated capacity
Load Cell Type: IP67, aluminum, single point / C3
Load Cell Cable: 2m L x 6-wire
Load Cell Rated Output: 2 mV/V ± 10%
Load Cell Excitation Voltage: Maximum 20V (AC/DC) / Recommended 5to15V (AC/DC)
Load Cell Input / Output Resistance: 410 ± 10 Ωs / 350 ± 4 Ωs
Base Dimension (AxBxCxDxE) (mm): 550 x 420 x 125 x 70 x 580
Shipping Dimensions (mm): 750L x 710W x 230H
Net / Shipping Weight: 24.5 kg / 27 kg

IQ/OQ/PQ service: Yes, possible

Model: D15QR
Capacity (Max): 15kg
Construction: 304 stainless steel pan, painted carbon steel frame, non-slip rubber leveling feet
Leveling Components: Externally visible level bubble and adjustable leveling feet
Operating Temperature : -10°C to 40°C
Safe Overload Capacity: 150% of rated capacity
Load Cell Type: IP67, aluminum, single point / C3
Load Cell Cable: 2m L x 6-wire
Load Cell Rated Output: 2 mV/V ± 10%
Load Cell Excitation Voltage: Maximum 20V (AC/DC) / Recommended 5to15V (AC/DC)
Load Cell Input / Output Resistance: 410 ± 10 Ωs / 350 ± 4 Ωs
Base Dimension (AxBxCxDxE) (mm): 305 x 305 x 95 x 52 x 335
Shipping Dimensions (mm): 490L x 410W x 440H
Net / Shipping Weight: 12.2 kg / 14.2 kg

IQ/OQ/PQ service: Yes, possible

Model: D60VR
Indicators: Check specification for T31P and T32XW indicators
Construction: 304 stainless steel pan and frame, non-slip rubber leveling feet
Net Weight: 9 kg
Shipping Weight: 11 kg
Load Cell Protection / Class*: IP67, stainless steel, single point / C3
Capacity (max) x Readability (d): 60 kg x 10 g
Maximum Resolution: 1:6000
Capacity (max) x Approvable Readability (e): 60 kg x 20 g
Approval Resolution (n max): 1:3000
Load Cell Capacity: 100 kg
Load Cell Cable: 2m L x 6-wire
Load Cell Rated Output: 2 mV/V ± 10%
Load Cell Excitation Voltage: Maximum 20V (AC/DC) / Recommended 5to15V (AC/DC)
Load Cell Input / Output Resistance: 410 ± 10 Ωs / 350 ± 4 Ωs
Leveling Components: Externally visible level bubble and adjustable leveling feet
Operating Temperature : -10°C to 40°C
Safe Overload Capacity: 125% of rated scale capacity
Base Dimensions (A x B x C x D x E): 355 x 305 x 123 x 75 x 380 mm
Shipping Dimensions (W x D x H): 642 x 497 x 212 mm

IQ/OQ/PQ service: Yes, possible

Model: D30VR
Indicators: Check specification for T31P and T32XW indicators
Construction: 304 stainless steel pan and frame, non-slip rubber leveling feet
Net Weight: 9 kg
Shipping Weight: 11 kg
Load Cell Protection / Class*: IP67, stainless steel, single point / C3
Capacity (max) x Readability (d): 30 kg x 5 g
Maximum Resolution: 1:6000
Capacity (max) x Approvable Readability (e): 30 kg x 10 g
Approval Resolution (n max): 1:3000
Load Cell Capacity: 50 kg
Load Cell Cable: 2m L x 6-wire
Load Cell Rated Output: 2 mV/V ± 10%
Load Cell Excitation Voltage: Maximum 20V (AC/DC) / Recommended 5to15V (AC/DC)
Load Cell Input / Output Resistance: 410 ± 10 Ωs / 350 ± 4 Ωs
Leveling Components: Externally visible level bubble and adjustable leveling feet
Operating Temperature : -10°C to 40°C
Safe Overload Capacity: 125% of rated scale capacity
Base Dimensions (A x B x C x D x E): 355 x 305 x 123 x 75 x 380 mm
Shipping Dimensions (W x D x H): 642 x 497 x 212 mm

IQ/OQ/PQ service: Yes, possible

Model: D300BX
Indicators: Check specification for T31P and T32XW indicators
Construction: 304 stainless steel pan, painted carbon steel tubular frame, non-slip rubber leveling feet
Net Weight: 28 kg
Shipping Weight: 32 kg
Load Cell Protection / Class*: IP67, aluminum, single point / C3
Capacity (max) x Readability (d): 300 kg x 50 g
Maximum Resolution: 1:6000
Capacity (max) x Approvable Readability (e): 300 kg x 100 g
Approval Resolution (n max): 1:3000
Load Cell Capacity: 500 kg
Load Cell Cable: 2.3m L x 6-wire
Load Cell Rated Output: 2 mV/V ± 10%
Load Cell Excitation Voltage: Maximum 20V (AC/DC) / Recommended 5to15V (AC/DC)
Load Cell Input / Output Resistance: 410 ± 10 Ωs / 350 ± 4 Ωs
Leveling Components: Externally visible level bubble and adjustable leveling feet
Operating Temperature : -10°C to 40°C
Safe Overload Capacity: 125% of rated scale capacity
Base Dimensions (A x B x C x D x E): 650 x 500 x 143 x 90 x 675 mm
Shipping Dimensions (W x D x H): 1,022 x 687 x 247 mm

IQ/OQ/PQ service: Yes, possible

Model: T32MC
Full Scale Capacity Range: 5 to 20,000 lb or kg
Displayed Resolution: 1:20,000 max / 1:6,000 NTEP Certified / Measurement Canada Approved
Construction: ABS plastic front panel with painted carbon steel rear housing; includes painted carbon steel table-wall mount bracket
Weight Display: 6-digit, 7-segment LCD, 1 in. / 25 mm digit height, with high-contrast white LED backlight
Keyboard: 4-button mechanical switches, raised tactile keys
Weighing Units: lb, oz, lb-oz, kg, g
Extra Functions/Modes: Parts Counting, Display Hold, Checkweighing, Weight Accumulation
Checkweigh Display: 3 LED: Red-green-yellow (Over-Accept-Under)
Minimum Average Piece Weight: 1d
Load Cell Excitation / Input Sensitivity: 5V DC / up to 3 mV/V (min 1 µV/d)
Load Cell Drive: Up to four 350 load cells
Stabilization Time: Within 2 seconds
Zeroing Range: 2% or 100% of capacity
Auto-Zero Tracking: Off, 0.5, 1 or 3 scale divisions
Span Calibration: 5 lb or 5 kg to 100% capacity
Interface: Bidirectional RS232C
Operating Temperature Range: 14°F to 104°F / -10°C to 40°C, Maximum relative humidity 80 % for temperature up to 31°C / 88°F, decreasing linearly to 50 % relative humidity at 40°C / 104°F, non condensing
Power: 9-12 VDC, 0.5A, external AC adapter
Enclosure Dimensions (W x D x H) (check pictures): 7.8 x 1.8 x 5.2 in / 198 x 46 x 132 mm
Net Weight: 1.5 lb / 0.7 kg
Shipping Dimensions (W x D x H): 10.7 x 9.2 x 7.2 in / 271 x 234 x 182 mm
Shipping Weight: 4.0 lb / 1.8 kg

IQ/OQ/PQ service: Yes, possible
